ID 1 Source Portable Laser Welder

Alliance ID1 Source Fiber Laser Welder

A SMALL LASER WELDER THAT CAN BE SEAMLESSLY INTEGRATED INTO EXISTING PRODUCTION LINES
SEE THE ID1 SOURCE IN ACTION
Book a custom demo
ID1 Source fiber laser welder logo

Get to know the ID1 Source Portable Fiber Laser Welder

Built to deliver precision fiber laser welding in a compact, portable package, the ID1 Source small laser welding machine is ideal for spot-welding and can be seamlessly integrated into existing production lines that require laser welding technology.

The ID1 Source features a lightweight head for mounting, changeable working distance lens options, and a compact laser with tablet control for easy integration into manual, automated, and robotic equipment. With real-time viewing and programmable welding formulas, the ID1 Source the portable fiber laser welder for in-house production, research work, and more.

DOWNLOAD PRODUCT SPECS

ID1 Source   Features

  • Versatility Icon

    Application versatility

    Tool steel, stainless steel, carbon steel, titanium, aluminum, nickel, copper, and beryllium

  • Laser Icon

    High pulse-to-pulse stability

  • Optics Icon

    Real-time laser viewing

    Leica optics ensures pinpoint accuracy on every weld

  • Ringlight Icon

    Integrated LED ring light for superior visibility

ID1 Source  Benefits

  • Welding Icon

    Ideal for spot welding, seam welding, and additive wire welding applications

  • Fit Icon

    Compact cabinet footprint

  • Setting Icon

    Full parameter control

  • Accuracy Icon

    95% stability for consistent, reliable laser welds

  • Modular Icon

    Rapid integration into existing production lines that require laser welding technology

EXPLORE THE ID1 SOURCE LASER WELDING SYSTEM

ID 1 Product Specs
  • 30 J maximum pulse energy
  • 3000 W maximum peak power
  • 300 W maximum average power
  • 30 J maximum pulse energy
  • 3000 W maximum peak power
  • 300 W maximum average power

  • TECHNICAL DATA ID1 UR ROBOTIC LASER WELDING SYSTEM
    LASER SAFETY CLASS CLASS 4 STANDARD
    BEAM SOURCE IPG FSS – FIBER LASER
    WAVELENGTH 1070 nm
    ENERGY ADJ MODE 10 – 100 %
    VOLTAGE 220 V Single Phase
    PULSE WIDTH 0.1 – 20 ms
    PULSE FREQUENCY 1-50 hz
    PULSE FILL –
    MODES PULSED / CW
    FOCAL LENGTH 200 mm STANDARD
    SPOT SIZE 0.002″ – 0.060″
    MICROSCOPE LEICA 10x STEREO MICROSCOPE
    ILLUMINATION INTEGRATED LED RING LIGHT
    PARAMETER SETTINGS N/A
    ENERGY MEASUREMENT N/A
    CONTROLLER TABLET DRIVEN
    INTERFACE EXTERNAL INPUT TRIGGER
    SHIELDING GAS SUPPLY FLEXIBLE NOZZLE WITH GAS LENS FILTER SYSTEM
    COOLING SYSTEM AIR COOLED
    COOLING OPTION N/A
    POWER CONSUMPTION N/A

  • TECHNICAL DATA FSS 300 W
    MAX. PULSE ENERGY 30 J
    MAX. PEAK POWER 3000 W
    MAX. AVGERAGE POWER 300 W


  • TECHNICAL DATA FSS 450 W
    MAX. PULSE ENERGY 45 J
    MAX. PEAK POWER 4500 W
    MAX. AVGERAGE POWER 450 W

  • TECHNICAL DATA FSS 300 W
    MAX. PULSE ENERGY 60 J
    MAX. PEAK POWER 6000 W
    MAX. AVGERAGE POWER 600 W

Still not sold on the Alliance ID1 Source Portable Fiber Laser?

The Alliance ID1 Source offers industry-leading beam quality, high energy efficiency, and maximum diode lifespan (up to 100,000 hours) for increased uptime. Air-cooled operation eliminates water cooling and reduces maintenance, making this fiber laser system both cost-effective and reliable.
