Get to know the ID1 FW Fiber Laser Welding Station

The ID1 FW is a hands-on laser welding workstation with a compact footprint for smaller shops or jobs. With the same full range of processing capabilities as the ID1, the ID1 FW reduces your shop footprint and elevates weld versatility and flexibility.

Whether in the field or in the shop, the ID1 FW laser welding workstation uses fiber laser technology for a robust, precise mold solution in a compact package.

DOWNLOAD PRODUCT SPECS

ID1 FW Laser   Features

  • Adjustments Icon

    Complete manual adjustments

  • Size Icon

    XYZ+R slotted table for small parts and molds

  • Joystick Icon

    3-axis joystick control

  • Configuration Icon

    Variety of head position configurations

ID1 FW Laser  Benefits

  • Versatility Icon

    Application versatility

    Tool steel, stainless steel, carbon steel, titanium, aluminum, nickel, copper, and beryllium

  • Fit Icon

    Compact footprint

    Comes standard with its own workbench to reduce shop footprint

  • Electricity Icon

    Power & Energy

    Up to 6000W peak power and 60J pulse energy

  • Productivity Icon

    Minimal parts wear

    Maximizing uptime and productivity

EXPLORE THE ID1 FW LASER WELDING SYSTEM

ID 1 FW Product Specs
  • 30 J maximum pulse energy
  • 3000 W maximum peak power
  • 300 W maximum average power
  • 30 J maximum pulse energy
  • 3000 W maximum peak power
  • 300 W maximum average power

  • TECHNICAL DATA ID1 FW FIBER LASER WELDER
    LASER SAFETY CLASS CLASS 4 STANDARD
    BEAM SOURCE IPG FSS – FIBER LASER
    WAVELENGTH 1070 nm
    ENERGY ADJ MODE 10 – 100 %
    VOLTAGE 22 V Single Phase
    PULSE WIDTH 0.1 – 20 ms
    PULSE FREQUENCY 1-50 hz
    PULSE FILL –
    MODES PULSED / CW
    FOCAL LENGTH 200 mm
    SPOT SIZE 0.002″ – 0.060″
    MICROSCOPE LEICA 20x MICROSCOPE
    ILLUMINATION INTEGRATED LED RING LIGHT
    PARAMETER SETTINGS N/A
    ENERGY MEASUREMENT N/A
    CONTROLLER 3 AXIS HAUL EFFECT WITH LASER TRIGGER
    INTERFACE N/A
    SHIELDING GAS SUPPLY FLEXIBLE NOZZLE WITH GAS LENS FILTER SYSTEM
    COOLING SYSTEM AIR COOLED
    COOLING OPTION N/A
    ELECTRICAL SUPPLY TRANSFORMER
    POWER CONSUMPTION N/A


  • TECHNICAL DATA FSS 300 W
    MAX. PULSE ENERGY 30 J
    MAX. PEAK POWER 3000 W
    MAX. AVGERAGE POWER 300 W


  • TECHNICAL DATA FSS 450 W
    MAX. PULSE ENERGY 45 J
    MAX. PEAK POWER 4500 W
    MAX. AVGERAGE POWER 450 W

  • TECHNICAL DATA FSS 300 W
    MAX. PULSE ENERGY 60 J
    MAX. PEAK POWER 6000 W
    MAX. AVGERAGE POWER 600 W

Still not sold on the Alliance ID1 FW Fiber Laser Welding Workstation?

With the perfect blend of full-service workstation and compact, easy-to-use operation, the ID1 FW Fiber Laser Welding Station uses fiber semiconductor diodes for up to 100,000 hours of consistent, precise mold repair and maintenance. Compact and intuitive, this fiber laser workstation packs a punch.
