ID 1 Fiber Laser Welder

Alliance ID1 Fiber Laser Welding Machine

A Versatile, Manually Adjusted Fiber Laser Welder
See The Id1 In Action
Book a custom demo
ID1 laser welding machine logo

Get to know the ID1 Fiber Laser Welder

A hands-on fiber laser industrial welder, the ID1 Fiber Laser Machine features a small footprint without sacrificing power and reliability. A manually adjusted design eliminates the chance of mechanical failure, reducing maintenance costs and maximizing uptime.

Solid state fiber laser technology and superior versatility make the ID1 Fiber Laser Machine a true workhorse that’s ideal for any in-house injection mold application. With an Alliance fiber laser welder, flexibility, reliability, and consistency are just part of the package.

DOWNLOAD PRODUCT SPECS

ID1 Fiber Laser   Features

  • Adjustments Icon

    Complete manual adjustments

  • Rotation Icon

    Full 360° rotation

  • Joystick Icon

    3-axis joystick for simplified, intuitive operation

  • Configuration Icon

    Wide variety of head position configurations

  • Temperature Icon

    Air cooled with high ambient air temperature operating capabilities

ID1 Fiber Laser  Benefits

  • Versatility Icon

    Application versatility

    Tool steel, stainless steel, carbon steel, titanium, aluminum, nickel, copper, and beryllium

  • Parts Icon

    Fewer parts

    Less wear and tear and reduced maintenance costs

  • Laser Icon

    Precise control

    Enables more intricate welds

  • Plug Icon

    Superior wall plug efficiency

EXPLORE ID1 FIBER LASER WELDING SYSTEM

ID 1 Product Specs
  • 30 J maximum pulse energy
  • 3000 W maximum peak power
  • 300 W maximum average power
  • 30 J maximum pulse energy
  • 3000 W maximum peak power
  • 300 W maximum average power

  • TECHNICAL DATA ID1 FIBER LASER WELDER
    LASER SAFETY CLASS CLASS 4 STANDARD
    BEAM SOURCE IPG FSS – FIBER LASER
    WAVELENGTH 1070 nm
    ENERGY ADJ MODE 10 – 100 %
    VOLTAGE 22 V Single Phase
    PULSE WIDTH 0.1 – 20 ms
    PULSE FREQUENCY 1-50 hz
    PULSE FILL –
    MODES PULSED / CW
    FOCAL LENGTH 200 mm
    SPOT SIZE 0.002″ – 0.060″
    MICROSCOPE LEICA 20x MICROSCOPE
    ILLUMINATION INTEGRATED LED RING LIGHT
    PARAMETER SETTINGS N/A
    ENERGY MEASUREMENT N/A
    CONTROLLER 3 AXIS HAUL EFFECT WITH LASER TRIGGER
    INTERFACE N/A
    SHIELDING GAS SUPPLY FLEXIBLE NOZZLE WITH GAS LENS FILTER SYSTEM
    COOLING SYSTEM AIR COOLED
    COOLING OPTION N/A
    ELECTRICAL SUPPLY TRANSFORMER
    POWER CONSUMPTION N/A

  • TECHNICAL DATA FSS 300 W
    MAX. PULSE ENERGY 30 J
    MAX. PEAK POWER 3000 W
    MAX. AVGERAGE POWER 300 W


  • TECHNICAL DATA FSS 450 W
    MAX. PULSE ENERGY 45 J
    MAX. PEAK POWER 4500 W
    MAX. AVGERAGE POWER 450 W

  • TECHNICAL DATA FSS 300 W
    MAX. PULSE ENERGY 60 J
    MAX. PEAK POWER 6000 W
    MAX. AVGERAGE POWER 600 W

Still not sold on the Alliance ID1 Fiber Laser Welder?

With a compact, shop-friendly design, continuous wave laser modes, and fiber semiconductor diodes with up to 100,000 hours of operation, the ID1 Fiber Laser Welder seamlessly integrates with existing shop equipment for precise, reliable operation.
